Kubota SE6000
SE6000 Ultra Heavy-Duty Mulcher
Maximum efficiency mulcher with dual mounting capability
The Kubota SE6000 mulcher is a very robust machine designed for the most demanding conditions in mulching grass, pastures, overgrown vegetation, stubble, and fallow land when attached to a CAT II three-point hitch tractor or to the front hitch of the tractor. This ultra-heavy-duty machine features dual-sided mounting capability and maximum working tool efficiency for the most challenging professional applications.
Equipped with heavy-duty mulching hammers as standard and suitable for tractors up to 160 HP, the SE6000 delivers exceptional performance with a large number of working tools (hammers) for very high efficiency. The central gearbox integrated in the mounting head ensures the PTO shaft remains at the same angle in all positions, even when working with maximum 550mm displacement. Perfect for professional operations requiring maximum efficiency and versatility.
Key Features:
- Dual-sided mounting head allows front or rear tractor connection
- Rear support cylinder mounted as standard for maintaining working height
- Freewheel delivered as standard – integrated in main gearbox
- Hydraulic lateral displacement 550mm for precision positioning
- Automatic tensioning of V-belts for consistent performance
- High rotor speed – 1949 RPM for superior cutting efficiency
- Dual PTO speeds 540/1000 RPM for maximum flexibility
- CAT II three-point hitch compatibility
- Large number of working tools (hammers) for very high efficiency
- Walterscheid gimbal supplied as standard
Construction Details:
- Hydraulic lateral displacement up to 550mm ideal for field edge mulching
- Transmission with integrated freewheel and five-belt drive with automatic tensioning
- High-performance rotor with high rotation speed ensures excellent crushing efficiency
- Reversible reels allow operation with 540 or 1000 RPM input speeds
- Dual-sided mounting head allows front or rear tractor attachment
- 245mm diameter cylinder with integrated bearings and easy working height adjustment
- Central gearbox maintains constant PTO shaft angle in all positions
Technical Specifications:
| Specification | Value |
|---|---|
| Model | SE6000 |
| Suitable for Tractors | Up to 160 HP |
| PTO Speeds | 540/1000 RPM |
| Rotor Speed | 1949 RPM |
| Hitch Type | CAT II three-point |
| Hydraulic Displacement | 550 mm |
| Mounting Options | Front or rear tractor connection |
| Cylinder Diameter | 245 mm |
| Drive System | Five-belt with automatic tensioning |
| PTO Shaft | Walterscheid gimbal |
| Gearbox Type | Central integrated in mounting head |
| Blade Type | Heavy-duty mulching hammers |
| Working Tools | Large number for maximum efficiency |
| Belt Tensioning | Automatic V-belt tensioning |
| Reel Type | Reversible for dual PTO speeds |
