Kubota Flat (Rotary) Mowers – Compact Range

Flexibility, ease of use, and safety are the three main characteristics of the flat mowers with rear mounting. Designed and manufactured using the latest technologies and advanced construction systems, they are ideal for tractors ranging from 12 to 60 HP.

Available working widths are 1200, 1500, 1800, and 2350 mm, making them suitable for all types of grass areas—from terrains to golf courses, sports fields, parks, and grass areas near highways and access roads. Four large adjustable support wheels always ensure precise cutting heights from 25 to 100 mm. Classic pneumatic tires can also be supplied for all models.

All models are based on a support carriage made from a single cold-rolled steel block. Durability and compactness are two more key attributes of this adaptable and user-friendly machine.

Series TC Versions:

  • TC 480NSLD, TC 590NSLD, TC 710NSLD with side discharge
  • TC 480NSRD, TC 590NSRD, TC 710NSRD, and TC 910NSRD with rear grass discharge

Additional Features:

  • Easily adjustable cutting height by sliding the hinge pads
  • “Floating” 3-point hitch allowing precise terrain contour tracking for quality cutting
  • Adjustable pre-load strap of 350 mm with a single screw

Front Mounting Models

The cutting decks in the F series come with cutting widths of 1200, 1500, and 1800 mm and are compatible with tractors from 12 to 60 HP with a standard Cat 1 hitch.

Thanks to their robust design and ease of use, mowing with the F series is extremely flexible. Their excellent cutting performance makes them a great solution for maintaining all types of grass or green areas.

Each model can be converted with a mulching kit, reducing time and costs when used correctly.

Important Features:

  • 3-point hitch category 0/1
  • SICMA gearbox with tapered roller bearings, valve, and service window
  • Rear grass discharge system
  • Grease lubrication system
  • Front roller (FA 2100)
  • Rotating solid wheels with adjustable height, sealed and greased bearings for long life
  • Floating upper hinge
  • Gearbox cover made of iron or plastic
  • Adjustable depth lower hinges
  • ES safety covers
  • Polyester powder coating system
